Top Hat SS High Amp Solid State Time Delay Relay

This product is no longer available.


 Find Distributors                      Local Sales Reps


For Direct OEM/Distributor Pricing, Contact Us At: [email protected]
Shipping: 2-3 Business Days

Go to 7601 Page for Details on Next Generation TH Series TDRs

VEHICLE AVAILABILITY

Eliminate battery jump start service calls and improve your fleets' vehicle availability.

BATTERY LIFE

Extend your fleet's battery life and reduce/eliminate the need for spare vehicle battery storage.

AUTO OFF

Automatic power off after a user-determined time for monitor system voltages and time-out counts.

Warranty

Engineered, assembled, and tested in the USA. Egis Mobile Electric provides a two year warranty on the Top Hat SS.

FEATURES / SPECIFICATIONS

The Top H.A.T. SS is a high amperage timed disconnect switch with a high reliability 180-AMP solid state relay and integrated thermal circuit breaker built in, configurable by PC and USB serial cable for determining optimal system settings. Custom factory-programming of desired settings is available for production level orders.

  • Self-contained timing and switching functionality, no external circuit breaker required

  • Draws ten times less power and current than high-amp relay coils

  • Programmable delay in tenths of a minute from 6 seconds to 4.5 days

  • Local LED for system status and diagnostics

  • Optional ignition key input (recommended for emergency vehicle applications)

  • Low Voltage Protection (voltage and time configurable, i.e. turn off when system voltage falls below 10.5-Volts for 15-Seconds)

  • Configurable Over Voltage Protection to protect sensitive load-side electronics

  • Kill switch input (turns output off)

  • Configured via Computer with standard USB serial cable

  • Technician debug mode, manually turn output on or off with PC when connected with optional cable

  • Settings can be updated in the field if necessary

DOWNLOADS



6301 Sales Sheet & Installation Instructions
