Fuse Block, Split Buss, 13 Circuit + Ground, 200 A, 12/24V PDM - 14

    81.50 81.5 USD 81.50


    This combination does not exist.

     Find Distributors         Local Sales Reps

    For B2B Pricing, Contact Us At: sales@egismobile.com


    Applications / Problems This Solves

    Three (3) High-Amp (1-50A) Outputs Allow Protection All Circuits with One Solution

    Compact Solution Combines Intelligent Battery Protection, Power Switching, Circuit Protection, Ground Return Buss, and Optional Manual Override Switch.

    Reduce Install Space and Total Installed Cost with Integrated Ground Return.

    Expandable Up to 31 Fused Outputs with RT or CT series Fuse Blocks

    Feature Summary

    Protects Branch Circuits By Accepting ATM-Mini Series Style Fuses.

    Bulletproof Construction
     Designed With High Temperature Materials and Stainless Steel Self-locking Hardware Allow Mounting Anywhere on Vehicle.

    Supports SAE Circuit Protection Standards
     for thermal/short circuit events.

    4 Year Industry Leading Warranty

     Focal Features

    Protective Terminal Cover

    Ensures input and output power terminals and screws do not short circuit to each other or to ground.

    Three (3) Flexible High Amp Fused Outputs

    Protects a wider range of loads by offering two paralleled mini fuses, one or both positions may be used.

    Robust Input & Output Terminals

    M6 stainless steel terminals and self-locking nuts with tin plated copper pads.

    Integrated Ground Return Block

    Receives up to 14 ground return wires and provides one high amp return to the battery.

    Integrated Label Recesses

    Convenient recesses for optional weatherproof label set makes circuit identification easy.

    Stainless Terminal Screws

    High quality stainless steel hardware ensure corrosion free operation.

    Terminal Reference Guide

    Handy schematic indicates fuse ratings, output groups and grounding buss on reverse of unit for quick reference.

    Large Wire Landing Pad

    Ensures reliable and secure connection is maintained for duration of install and protects ring terminal from deformation.
