Description
Applications / Problems This Solves
Supports Multiple Engines or Independent Charge Systems by incorporating two independent start or engine isolation inputs to allow isolation of charge sources when both are active to maximize charging performance.
Feature Summary
Intuitive Manual Control option simplifies operation and awareness of state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions)
Simple Programmability via simple dip switches allows each individual relay function significant flexibility for OEMs and installers.
Plug & Play Compatible with Legacy Competitor Products: Single, dual and triple relays options available with DTM/ATM connectors pin for pin compatible with ML Series Bi-stable Relays.
TOTAL CONTINUOUS
CURRENT (AMPS)
500
MAX CRANKING
CURRENT (AMPS)
1500
MECHANICAL SWITCHING LIFE
1,000,000 Cycles
VOLTAGE RANGE
(V DC)
8 - 36
OFF-STATE CURRENT DRAW (mA)
1.3
STATE CHANGE CURRENT
5A @ 12 Vdc
3A @ 24 Vdc
Focal Features
Lithium Battery System Ready
Designed for modern Lithium battery based electrical system applications that often require higher ON/OFF charge voltage settings over legacy battery chemistries.
LED Status Display
Easy to see front facing LED indicator provides visual device status, remote LED replicates local on-device LED
3-Position Manual Override
Force each individual relay Open or Closed and optionally leave knob in either position to lock relay in either condition.
40 Circuit Label Sheet Included
Convenient recesses for included weatherproof label set makes circuit and relay identification easy. Blank labels for custom applications.
Protective Cover Included
Protects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.
Stainless Hardware
Corrosion is no issue with quality stainless steel studs and self locking flanged nuts.
Programmable
Via dip switches located under protective cover. An easy to use configuration guide on reverse make custom settings a breeze to configure for a wide variety of applications.
Integrated Vent
High quality Gortex vent regulates internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.
XD Series Related Options
Manual Override
Intuitive to use front facing yellow manual override knob makes manual control easy but if it's not needed, ask about our lever-free models!
Link Bars
Save install space by linking XD Relays together for even more capability with our optional 8790 and 8791 Links Bars.
Smaller Footprint
XD Relays offers high Amp rating in a smaller package than competitive solutions, reducing install space requirements to a minimum.
Wire/Connector
Flexible install wiring options with either tinned wires or optional Deutsch DTM compatible plug that provides optimal sealed protection.
Single/Dual/Triple
Available in single/dual/triple circuit configurations with a wide variety of options: manual override, relay functions, ACR, or remote battery disconnect.
