Applications / Problems This Solves
Resistor circuit protection ensure flyback voltage does not affect control signal circuitry. A great option for sensitive electrical systems.
High Intermittent Amperage rating of 300 amps for up to 3 seconds making this relay great for temporary high equipment start up amp draw applications.
Automotive Grade Connector ensures moisture and dust intrusion is kept from control circuitry.
High Temperature Rating of 125C/257F makes this a great relay for high temperature installation environments like engine bays and other low ventilation spaces.
Feature Summary
Dual Mounting Holes on either side for easy mounting with 1/4-20"/M6 1.25 Bolts or screws up to #14 screw.
Incorporate The Highest Quality Materials for superior performance and has a high 100,000 electrical switching cycle capacity.
Enhanced Vibration and Shock Protection, ensures enhanced reliability and a long service life and maintains electrical system operational readiness.
Information Sheet
.Step File
Key Specifications
Max INTERMITTENT
CURRENT @ 3 SEC (AMPS)
300
AMBIENT TEMPERATURE RATING (LOW/HIGH)
-40C/125C
MAX CONTINUOUS
CURRENT (AMPS)
180 @ 23C
ELECTRICAL ENDURANCE RATING (CYCLES)
1,000,000
On State Current Draw @ 24 vDC
163 mA
OPERATING VOLTAGE RANGE
17.6-32
Focal Features
Sealed Housing
IP67 rated housing keeps out moisture and ensure long term reliability.
Reinforced Mounting
Robust mounting tabs with strengthening gussets ensures relay stays mounted securely, even through vibration, heat and wire tension.
Terminal Protection
Shielded dual M6x1.0 terminals ensure protection from accidental contact shorts.
Delphi Metripak Connector
Automotive grade sealed control wire connector keeps out moisture from the control circuit.
