Description
Applications / Problems This Solves
Meets Aluminum Hull and US Coast Guard Safety Requirements For Isolated Switching of Both Positive and Ground Leads.
Multiple Voltage Capability For Multi Voltage/Multi Battery Chemistry Battery Applications With 12 & 24V Switching Capability in One Device.
Remote ON/OFF/Auto Inputs Allows Forced Close or Open or Allowing Automatic Operation Based on Voltage Sensing
Flexible Functionality via Dip Switches: Low Voltage OFF Set-Point, Delay Off Time, and Voltage Differential for Warning Signal
Product Video
Feature Summary
Intuitive Manual Control option simplifies operation and awareness of state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions)
Simple Programmability via simple dip switches allows each individual relay function significant flexibility for OEMs and installers.
35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts.
90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality
Step File
TOTAL CONTINUOUS
CURRENT (AMPS)
500
MAX CRANKING
CURRENT (AMPS)
1500
MECHANICAL SWITCHING LIFE
1,000,000 Cycles
VOLTAGE RANGE
(V DC)
8 - 36
OFF-STATE CURRENT DRAW (mA)
1.3
STATE CHANGE CURRENT
5A @ 12 Vdc
3A @ 24 Vdc
Focal Features
LED STATUS DISPLAY
Easy to see front facing LED indicator provides visual device status, remote LED replicates local on-device LED
3-POSITION MANUAL OVERRIDE
Force each individual relay Open or Closed and optionally leave knob in either position to lock relay in either condition.
40 CIRCUIT LABEL SHEET INCLUDED
Convenient recesses for included weatherproof label set makes circuit and relay identification easy. Blank labels for custom applications.
PROTECTIVE COVER INCLUDED
Protects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.
STAINLESS HARDWARE
Corrosion is no issue with quality stainless steel studs and self locking flanged nuts.
PROGRAMMABLE
Via dip switches located under protective cover. An easy to use configuration guide on reverse make custom settings a breeze to configure for a wide variety of applications.
SMALLER FOOTPRINT
XD Relays offers high Amp rating in a smaller package than competitive solutions, reducing install space requirements to a minimum.
INTEGRATED VENT
High quality Gortex vent regulates internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.
XD Series Related Options
Manual Override
Intuitive to use front facing yellow manual override knob makes manual control easy but if it's not needed, ask about our lever-free models!
Wire/Connector
Flexible install wiring options with either tinned wires or optional Deutsch DTM compatible plug that provides optimal sealed protection.
Link Bars
Save install space by linking XD Relays together for even more capability with our optional 8790 and 8791 Links Bars.
Single/Dual/Triple
Available in single/dual/triple circuit configurations with a wide variety of options: manual override, relay functions, ACR, or remote battery disconnect.
