P/N: 8030
12 Position Distribution / Ground Block
-
12 position Screw Terminal block, can be used alone or in conjunction with fuse terminal blocks and a ground return block or a positive distribution block if proper circuit protection and wire gauges are utilized
-
100 Amp maximum, 30 Amp maximum per circuit
12 Position Sealed Bus Bar
-
Compact solution distributes or collects 12 circuits into 1, eliminates risk of loose screw connections, reduces instillation time, and protects connections.
-
Waterproof to IP66, IP67, and IP69K - Ignition protected for explosive environments
-
Multiple mounting orientations for optimal use of space or wire routing
-
150 Amp maximum total current, 20 Amp per circuit maximum.
-
Increase number of circuits tying 2 units together with optional bus bar connector.
